innoscan 1100

InnoScan 1100 - 3-Color ultra-high resolution scanner

Multiplexed whole-slide imaging

0.5μm pixel size, equivalent to 20x microscope magnification
High sensitivity : high performance analogical PMTs
3-color simultaneous confocal detection

Easy automation

Real-time autofocus or in-content focus system
24-slide autoloader for high-throughput applications
Automated image acquisition with Mapix software

Reliable and traceable results

Barcode reader
Accurate control of acquired images
Scanner supplied with a validation slide which verifies scanner performance

Technologie

Confocal detection

  • Optimize fluorescence detection
  • Assure good focalization all along the scan
  • Less background
  • SNR is increased by 2.5 times

Real-time autofocus

  • Detection idone through a spatial phinhole
  • Follows the slide movement and deformation in real time during the scan
  • Avoid all out-of-focus signal

Automatic barcode reader

  • Reliable and traceable results

All standard microscope slides format

  • Glass
  • Nitrocelluose coated glass
  • Plastic
  • Silicon wafer
  • Gold coated glass

Dynamic range

  • From > 104 to >106
  • Detect the lowest signals avoiding saturation.

Technical specifications

InnoScan 1100

PIXEL SIZE0.5 - 40μm
LASER EXCITATION WAVELENGTH488nm532nm635nm
COMPATIBLE FLUOROPHORES*Cy2, FITC
Alexa Fluor 458, Alexa Fluor 488
Cy3
Alexa Fluor 544, Alexa Fluor 555
Cy5, DRAQ 5 Alexa Fluor 647
LASER POWERAdjustable (2 laser powers)
LOADER CAPACITY1 slide
DETECTION TYPEReal-time confocal with 3 analog photomultipliers (PMT)
PMT GAINAdjustable from 0 to 100%
(Linear from 1 to 100%)
OPTICAL FILTER7 position filter wheel**
1 standard fluorescence and 1 neutral density filter per channel;5 additional filters on request
FOCUSReal-time autofocus
Manual focus: offset adjustment 300 μm range, 1 μm increment
SLIDE SIZECompatible with all standard microscope slides: 25-26 x 75-76 mm2 / 1” x 3” ; thickness: 0.9 - 1.2 mm
SCANNING AREAAdjustable up to 22 x 74 mm2
SCANNING SPEEDFrom 10 to 35 lines/second (l/s)
3.6 minutes per slide at 10 μm and 10.5min for an area 22x22 mm2 at 1μm
DYNAMIC RANGE> 104 in normal mode or > 106 in dynamic extension mode
UNIFORMITY> 95%
BARCODE READERAutomatic barcode reading
INTERFACEEthernet interface
IMAGE FORMATTIFF (16-bit and 20-bit in dynamic extension mode)
POWER SUPPLY~ 100-240 VAC, 1.2 A, 50-60 Hz
ACQUISITION SOFTWAREMAPIX (image acquisition and spot quantification software)
DIMENSIONS (LXDXH)316 x 549 x 432 mm3 12.5” x 21.6” x 17.0”
WEIGHT30 kg (66.1 lbs)

InnoScan 1100 AL

LOADER CAPACITY24 slides
DIMENSIONS (LXDXH)322 x 656 x 439 mm3 - 12.7” x 25.8” x 17.3”
WEIGHT35 kg (77.1 lbs)

* Non exhaustive list, please contact us for more information about fluorophore compatibility
Please contact us for any additional information.

Class I laser product for research use only
Specifications subject to change without notice contact us for the most recent specifications
